Fuel Systems

Fuel Handling &
Control Systems.

The efficiency of any combustion system starts with fuel preparation. We deliver precise metering, conditioning, and safety control from storage to the burner tip.

Solid Fuel Handling

Precise metering and dosing for coal and biomass.

Loss-in-Weight feeders, weigh feeders, and rotary airlocks designed for difficult-to-handle solid fuels. Ensures consistent feed rate to the burner for stable combustion.

Gravimetric feeding accuracy
Handling of diverse fuels: Coal, Petcoke, Biomass
Explosion-proof design available
Complete automation integration
Enquire NowDownload Brochure

Technical Specifications

Accuracy± 0.5% to 1%
CapacityUp to 50 TPH
MaterialCarbon Steel / Stainless Steel
ControlVFD based

Oil Handling & Heating

Filtering, pumping, and heating skids for heavy oils.

Automated skid-mounted units for unloading, transfer, pressurisation, and heating of heavy fuel oils (HFO/LDO) to ensure proper viscosity at the burner tip.

Duplex filters for continuous operation
Screw pumps for positive displacement
Electric or Steam/Thermic fluid heaters
Viscosity control automation
Enquire NowDownload Brochure

Technical Specifications

Flow Rate100 LPH to 30,000 LPH
PressureUp to 40 bar
TemperatureUp to 140°C
ViscosityUp to 380 cSt

Gas Regulation & Metering

Safety and precision for gaseous fuels.

Gas pressure reducing stations (PRS) and valve trains designed to ASME B31.8. Includes slamming shut-off valves, pressure regulators, flow meters, and safety vents.

Active and Monitor regulator configuration
Over-pressure shut-off (OPSO)
Under-pressure shut-off (UPSO)
Creep relief valves
Enquire NowDownload Brochure

Technical Specifications

Inlet PressureUp to 100 bar
Outlet Pressurembar to bar range
FlowUp to 10,000 Nm³/hr
StandardsIGEM / ASME / API
